Prima Klima activated carbon filter industry with 1200 m³/h and 250mm diameter
The premium carbon filters of the Prima Klima Industry Line are characterised by a remarkably high durability and an incomparable odour adsorption. The filters are refillable and have a 4 cm thick layer of premium, highly activated CTC75 carbon with a surface area > 1200 m² / g. This provides an exceptionally long contact time between air and carbon, which is very effective in eliminating odours. High-quality pressed metal parts ensure maximum stability and durability. The extra long flange provides a secure connection. This activated carbon filter (AKF) reliably filters any kind of unwanted odours from the exhaust air and is one of the most important points for indoor installation.
- The activated carbon filter must be connected to a suitable ducted fan.
- The filter is supplied ready for connection and with a pre-filter fleece.
- Approx. 99% of all odour molecules are absorbed.
The following points must be observed with activated carbon filters:
- Never smoke near the filter.
- Cigarette smoke reduces the service life of the activated carbon the most.
- The filter must never be used without a pre-filter.
- The pre-filter must be changed regularly.
- The specified cubic capacity of the filter must never be exceeded.
- The filter must be operated with a minimum of 25% of the cubic capacity.
- The air humidity should not permanently exceed 85%.
- The filter must not be in operation when cleaning the room.
- The filter must not come into contact with water under any circumstances.
Technical data:
- Weight: approx. 15.4 kg
- Height: approx. 750 mm without flange
- Diameter: approx. 330 mm
- Connection diameter: 250 mm
- Maximum air flow: 1800m³/h
- Optimum air flow: 1200m³/h
- Filling thickness: 40 mm
- Activated carbon: CTC80-3mm 10,4 Kg
-
Manufacturer: primaklima
- Diameter: 250 mm
- Item weight: 15,40 kg
-
Dimensions(LxWxH)
( Length × Width × Height ): 85,00 × 40,00 × 40,00 cm
