Secret Jardin DF16 Extractor Fan EC 150/250/350 m3/h speed/temperature control

The new Secret Jardin DF16 EC exhaust fan with smart click function can be mounted to the Ducting Flange system within seconds and without additional tools. It is intended to be used in combination with the SecretJardin Carbon Activated Carbon Filters CTC80. However, the EC fan can also be connected to other standard filters using a connector for Ducting Flange and the corresponding Rubber Ducts. The fan is equipped with a temperature control function and two heat sensors (inside or outside), depending on the size of your grow box (see picture). A high-quality EC motor (24V-40W) has also been installed. The housing is made of flame-retardant polyamide, reinforced with glass fibre (PA66 + 15% GF V0).

Setting the controllers:

• 1. Select your desired set temperature (TEMP°). The EC fan regulates the temperature with a deviation of +/- 2°C.
• 2. select the minimum exhaust air speed (EXT. MIN). So that the air can be exhausted even at low temperatures.
• 3. select the maximum exhaust air speed (EXT. MAX). Depending on the grow surface (see technical data).

Integrated and external temperature sensor

If the 2nd thermal sensor (external) is connected, the integrated sensor is switched off. So if you use the integrated temperature sensor, the EC fan runs at a minimum speed of 5%.

Volume test:
The measurement was taken 70cm in front of the tent without silencer.

• max. stage 150m3/h: 36 dB
• max. stage 250m3/h: 54 dB
• max. stage 350m3/h: 61 dB

Recommendation:

• level 150m3/h for a grow tent up to 60x60x160cm, recommended Carbon Filter DF16150.
• level 250m3/h for a grow tent up to 100x100x200cm, recommended Carbon Filter DF16250.
• level 350m3/h for a grow tent up to 120x120x200cm, recommended Carbon Filter DF16350.

Details:

• Compatible with all Secret Jardin grow tents
• 3-stage EC fan with 150/250/350 m3/h capacity
• Temperature control function and 2 heat sensors (integrated and external)
• Assembly without tools within seconds
• Connection to different flange sizes possible

Technical data:

• 3 speed: 150/250/350 m3/h
• Consumption: 35W
• Current: 1.5A
• Voltage: 110-220 V
• Frequency: 50/60 Hz
• Ambient temp.: min. 0°C/max. 40°C
• Dimensions (LxWxH): 25x25x21cm
• Protection class: IP54
• Length of power cable: 60cm
• Length of 2nd sensor cable: 240cm
• Weight: 1,5kg

Included:

• Adapator DF16 Ring
• 2nd Thermal Sensor (external)
• 24V Deported Power Supply, EU, UK, US Adaptor

An activated carbon filter is not included and must be ordered separately.
