Extraction Kit Prima Klima PKVS-125EC-TC 680m³/h

This powerful PrimaKlima 125EC-TC 580m³/h exhaust air set with its coordinated components is ideal for growing areas measuring 120x120 cm.

PrimaKlima has launched a new highlight with the PK125EC-TC duct fan, which impresses with its particularly high-quality workmanship, energy efficiency and very quiet operation. The duct fan has temperature control and integrated speed control, which is not only practical but also eliminates the need to purchase an optional speed controller.

The built-in EC motor from ebmpapst (made in Germany) impresses with its low power consumption, high pressure build-up, performance and particularly quiet operation. The integrated speed controller allows for continuous adjustment of the running performance without any annoying humming noises.

The temperature is continuously adjustable from 20-30°C, the motor speed min. + max. from 0-100%. The temperature sensor is approx. 2m Long.

Technical data PK125EC-TC 680m³/h:

• Voltage: 230 volts 50/60 Hz
• Power consumption: 0-170 watts / 0-0.74A (depending on speed)
• Throughput: max. 680 cbm/h
• Max. pressure: 1000 Pa
• Max. working temperature: 50 °C
• Diameter: 125 mm
• Plug cable approx. 2 metres long
• Temperature sensor cable approx. 2 metres long
• Weight: approx. 3.5 kg
• Made in Germany

The Prima Klima Eco Flat 440 m³/h ø125mm activated carbon filter provides effective odour removal at an unbeatable price-performance ratio. Powerful air filtration with a 3 cm thick layer of CTC80-3mm activated carbon. This activated carbon filter from the Eco series reliably filters all kinds of unwanted odours from the exhaust air and is one of the most important factors in indoor cultivation.

Technical data filter:

• Weight: 3.0 kg
• Height: 250 mm without flange
• Diameter: 230 mm
• Connection diameter: Ø125 mm
• Maximum air flow: 440m³/h
• Optimal air flow: 360m³/h
• Activated carbon: CTC80-3mm 1.6 kg

The set consists of the following items:

• 1 x PrimaKlima activated carbon filter Eco Flat 440m³/h ø125mm
• 1 x PrimaKlima PK125EC-TC tube fan 680m³/h climate controller
• 1 x Combi Flexible Pipe ø125mm, length 3 metres in one piece
• 1 x Mounting Collar ø125 mm
• 1 x Hose Clamp ø60 to 165 mm

Note: The set is delivered unassembled. Connect the tube fan and the activated carbon filter with the mounting sleeve; please use the hose clamp for the ventilation hose.

PLEASE NOTE: The maximum speed of the fan should not exceed the maximum capacity of the filter.
