Prima Klima Carbon Filter Carbocone 800m³/h ø125mm

Active Carbon Filters with improved conicalinner basket

Introducing Carbocone! A new line of activated carbon filters with improved patented conical design of the inner basket provides great benefits such as extended life, increased filtration efficiency by up to 30% and even saturation of activated carbon. Highly efficient filtration with activated carbon CTC80, same high quality as with Industry Line.

Carbocone activated carbon filters can be used wherever unwanted smells and air pollution occur.

Details:

• layer thickness: 5-6 cm
• conical inner basket ensures uniform flow of coal
• 30% better adsorption efficiency
• Lifetime up to 3 years
• 100% new CTC80-3mm Pellet coal
• refillable
• max. air humidity 90%
• the activated carbon filter must be connected to a suitable tube fan
• the filter is delivered ready for connection and with a pre-filter fleece
• About 99% of all odor molecules are absorbed

Technical data:

• Weight: 6.3 kg
• Height: approx. 625 mm without flange
• Diameter: approx. 200 mm
• Connection diameter: 125 mm
• Maximum air flow: 800m³/h
• activated carbon: CTC80-3mm 4,0 Kg

The following aspect are important for the use of activated carbon filters:

• Never smoke near the filter
• Cigarette smoke reduces the durability of the activated carbon significantly
• The filter should never be used without a pre-filter fleece
• The pre-filter has to be exchanged regularly
• Never exceed the specified cubic performance
• The filter has to be used with a minimum of 25% of the cubic-performance
• The humidity should not exceed 85% over a longer period
• During room cleaning, the filter has to be shut off
• Never let the filter get in contact with water
