SANlight STIXX 3-80, 70W – Maximum flexibility for every growth phase

The Undercanopy STIXX 3-80 consists of three powerful modules and is optimally designed for a cultivation area with a depth of 80 cm. It provides significantly better illumination of the lower plant areas, promoting vitality, uniform growth and higher yields.

Whether you use the STIXX as undercanopy lighting to promote yield and flower density in shaded plant zones or as a top light in multi-storey systems and vertical farming setups, you always benefit from optimal illumination of the entire cultivation area.

Thanks to the asymmetrical secondary optics, the light is directed through the foliage, minimising shadows and ensuring uniform photosynthetic activity from top to bottom.

SANlight STIXX as a toplight – maximum flexibility for every setup

The STIXX not only cuts a fine figure under the canopy – it can also be used as a fully-fledged toplight. Depending on the configuration, you can achieve 200 to over 1500 µmol/m²/s, perfect for:

• Veg setups
• Mother plants
• Young plant areas
• Intensively illuminated flowering systems

Thanks to the modular Smart Driver Technology, you can adjust the STIXX to suit your needs:

You decide whether you prioritise maximum efficiency or maximum light intensity. PPFD, energy consumption and output power – everything is under your control.

The balanced full spectrum with enhanced red content supports:

• vigorous vegetative development
• strong root formation
• and homogeneous flower quality from the upper to the lower canopy area

Built for tough everyday cultivation

The STIXX was developed specifically for professional and demanding environments. The IP68-sealed housing reliably protects the LEDs from:

• High humidity
• Dust
• Fertilisers
• Sulphur

The optically sealed secondary optics offer additional protection, are easy to clean and maintain consistent light output for many years.

Modular design – maximum scalability

SANlight Smart Driver Technology is the world's first fully modular system that controls multiple lights via a single driver.

The driver automatically detects:

• how many modules are connected
• how much power each module requires
• and dynamically adjusts the output

You can add, remove or rearrange modules at any time without having to rebuild your entire setup. Perfect for gradually adapting your lighting to increasing requirements.

Ideal for home growers

The STIXX series is particularly useful when an EVO luminaire would be too powerful or a double EVO installation offers no added value.

• It is ideal for:
• Low ceiling heights
• Small growing areas
• Modular lighting solutions

Advantages of the SANlight STIXX series at a glance

• Perfect for undercanopy, toplight and vertical farming setups
• Asymmetrical secondary optics for maximum homogeneity
• IP68 – absolutely reliable in humid environments
• Modular Smart Driver System for flexible, scalable installations
• Full spectrum light for growth & flowering
• Passively cooled – maintenance-free and silent
• Developed & manufactured in Austria – highest quality

Technical data STIXX 3-80

• Power consumption: 70 W
• Module efficiency: 3.1 µmol/J
• PPF (max. photon flux): 191µmol/s
• Beam angle: 90/135
• LM90 [h]: 90% light output achieved after: 53,000
• Max. operating voltage: 57 VDC
• Operating current: 1.25 A
• Weight: 1.03 kg
• Dimensions (LxWxH): 67.6 cm x W 8.5 cm x H 1.69 cm
• Protection class: IP68
• Permissible ambient temperature: 5-30 °C
• Max. relative humidity: 99%
• Emission wavelength: 400 - 780 nm
